qtz 4208 Topkit kind of Tower Crane 29 meter freestanding height tower kren

Name: qtz 4208 Topkit kind of Tower Crane 29 meter freestanding height tower kren
Brand: HYCM
Price: 24300 USD

China qtz 4208 Topkit kind of Tower Crane 29 meter freestanding height tower kren factory

Brand Name : HYCM

Model Number : QTZ40(4208) Tower Crane

Certification : CE, ISO, GOST, CU-TR

Place of Origin : China

MOQ : 1

Price : $24300-25900 per set

Payment Terms : TT, LC

Supply Ability : 40 sets per month

Delivery Time : 10 days after receiving the deposit or origin LC

Packaging Details : Naked packing, 3*40’HQ containers.

Condition : 100% New

Application : Buildings and projects

Type : Fixed with tower head

Max. load : 4 t

Jib length : 42 m

Tip. load : 0.8 t

Power supply : 380V/50Hz, 415V/50Hz, 220V/50Hz or according to clients need

Mast section : 1.5*1.5*2.2m

Main chord : 140*10mm

After sale service : Engineers available to service overseas

Contact Now

qtz 4208 Topkit kind of Tower Crane 29 meter freestanding height tower kren

Main Technical Parameters
1) Nominal Lifting Moment: 400KN.m
2) Working Range: 3-42m
3) Max. Lifting Capacity: 4t
4) Independent Standing Height: 29m
5) Attached Standard Height: 120m
6) Lifting Speed: 64.15/32.57/7.0, 32.14/15.60/3.5m/mim
7) Slewing Speed: 0.7/0.35r/min
8) Radius Changing Speed: 38.6/25.2m/mim
9) Climbing Speed: 0.4m/min

Specification

Model		QTZ40 (4208) Tower Crane
Working Radius (m)		42
Max. Load Capacity (T)		4
Tip Load (T)		0.8
Freestanding height (m)		29
Max. Height with anchorages (m)		120
Mast Section dimension (m)		1.5×1.5×2.2, angle steel 140×10mm
Hoisting Mechanis	Speed (m/min)	64.15/32.57/7.0, 32.14/15.60/3.5
	Motor power (kw)	15/15
Slewing Mechanism	Speed (r/min)	0.7/0.35
	Motor power (kw)	3.7
Trolleying Mechanism	Speed (m/min)	38.6/25.2
	Motor power (kw)	1.5/2.2
Jacking-up System	Speed (m/min)	0.4
	Motor power (kw)	4
Total Power (kw)		24.9
Power Supply		380V/50Hz, 415/50Hz, 220V/60Hz, ect

Application field: Building height up to 30 floors (120m), loading capacity up to 4t, jib length is 42m or short. If you have some special requirements, we will design new type of tower crane for you.

Abroad markets: The Middle East Regions, Southeast Asia, Africa, Russia, ect.

Certificate: ISO9001-2008, CE, GOST

Package: nude in 6*40"HQ or 7*40’HQ container

Payment terms: 30% in advance, 70% balance payment before shipment date

Delivery time: 30 workdays after receiving 30% advanced payment

Warranty: 12 months from the bill date (arrival of destination). And overseas service center is available.

Material: Q235 manganese steel

MOQ: 1 set (the more you buy, the cheap it is)

Pictures

qtz 4208 Topkit kind of Tower Crane 29 meter freestanding height tower kren Images
